Circuit Description

WARNING: This page is about a different car, the 2004 Lexus ES 330. However, it is still accessible from the selected car via links, so may be relevant.

The absorber control switch is a switch which selects the damping force mode of shock absorber.

Fig 1: Absorber Control Switch Circuit Description
G01438751Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
