Step 4 - Install Drive Belt

WARNING: This page is about a different car, the 2002 Toyota Avalon. However, it is still accessible from the selected car via links, so may be relevant.

Adjust drive belt tension. See INSPECT DRIVE BELT .

NOTE:

Use a torque wrench with a fulcrum length of 300 mm (11.81 in.).
Disconnect the clamp with engine wire.

Fig 1: Tightening Power Steering Vane Pump Bolts A & B

G01102402

Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Using SST, torque the bolt A. SST 09249-63010.
Torque: 29 N.m (300 kgf.cm, 22 ft.lbf) .
Torque the bolt B.
Torque: 43 N.m (440 kgf.cm, 32 ft. lbf) .
Connect the connector to the oil pressure switch.
