Removal & Installation (Avalon)

WARNING: This page does not describe the selected car, but rather 10 other vehicles, including the 2002 Toyota Tundra, 2002 Toyota Tacoma, 2002 Toyota Sienna, 2002 Toyota Sequoia, and 2002 Toyota Land Cruiser. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove "V" bank cover for access to ignition coils mounted on top of valve covers. See Figure.
  2. Disconnect electrical connector at ignition coil. Remove bolt and ignition coil. To install, reverse removal procedure. Tighten bolt for ignition coil to specification. See TORQUE SPECIFICATIONS .
