Inspection Procedure

WARNING: This page is about a different car, the 2002 Toyota Sequoia. However, it is still accessible from the selected car via links, so may be relevant.

Check Water Valve Damper Control Servomotor
Preparation:

Remove the REAR A/C EVAPORATOR .

Check:

Connect positive (+) lead to terminal 5 and negative (-) lead to terminal 4.

OK:

The lever turns smoothly to Warm side.

Fig 1: Testing Water Valve Damper Control Servomotor (Warm Side)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002

Check:

Connect positive (+) lead to terminal 4 and negative (-) lead to terminal 5.

OK:

The lever turns smoothly to Cool side.

Fig 2: Testing Water Valve Damper Control Servomotor (Cool Side)
Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
1. NG: Replace water valve damper control servomotor assembly.
2. OK: Go to next step.
Check harness and connector between integration control and panel and water valve damper control servomotor assembly.
1. NG: Repair or replace harness or connector.
2. OK: Check and replace integration control and panel.
