DTC 11, 15: Actuator Motor Circuit

WARNING: This page is about a different car, the 2002 Toyota Tundra. However, it is still accessible from the selected car via links, so may be relevant.

For DTC 11, 15: actuator motor circuit diagnostic procedure, see Fig 1 and Fig 2

Fig 1: Diagnosing Stop Light Switch Circuit (1 Of 2)
G00369782Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
Fig 2: Diagnosing Stop Light Switch Circuit (2 Of 2)
G00369783Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
