Brake Pedal Height & Free Play
WARNING: This page is about a different car, the 2004 Lexus ES 330. However, it is still accessible from the selected car via links, so may be relevant.
- Measure pedal height from floor board to face of pedal pad. See BRAKE PEDAL HEIGHT & FREE PLAY SPECIFICATIONS table. If pedal height is incorrect, go to next step.
- Remove undercover panel, lower pad and air duct. See Fig 1. Disconnect stop light switch wiring harness connector. Loosen stoplight switch lock nut, and remove stoplight switch. Loosen brake pedal-to-power brake unit push rod lock nut. Adjust pedal height by turning brake pedal push rod. Tighten push rod lock nut to specification. See TORQUE SPECIFICATIONS .
- Install stop light switch and connect brake light switch wiring harness connector. Push in brake pedal .2-.39 in. (5-10 mm) and turn stop light switch to lock the nut in position where brake light goes off. After installation, push in brake pedal .2-.39 in. (5-10 mm) and check that brake light illuminates.
- Turn ignition off. Depress brake pedal several times until power brake unit is depleted. Push brake pedal by hand until a second point of resistance is felt, then measure the difference. Ensure pedal free play is as specified. See BRAKE PEDAL HEIGHT & FREE PLAY SPECIFICATIONS table.
- If incorrect, check stop light switch clearance. See STOP LIGHT SWITCH CLEARANCE table. If clearance is OK, trouble shoot brake system. Install instrument panel components as necessary.
BRAKE PEDAL HEIGHT & FREE PLAY SPECIFICATIONS
| Application | In. (mm) |
|---|---|
| Brake Pedal Height | 5.673-6.067 (144.1-154.1) |
| Brake Pedal Free Play | 0.04-0.24 (1-6) |
STOP LIGHT SWITCH CLEARANCE
| Application | In. (mm) |
|---|---|
| ES 330 | .02-.098 (.5-2.5) |
