Reassembly (Lower Valve Body A-241 Series)
WARNING: This page does not describe the selected car, but rather 9 other vehicles, including the 1994 Toyota MR2, 1993 Toyota MR2, 1993 Toyota Celica, 1992 Toyota MR2, and 1992 Toyota Corolla. However, it is still accessible from the selected car via links, so may be relevant.
- Coat all components with ATF. To reassemble, reverse disassembly procedure. Note special procedures listed.
- During lower valve body reassembly, install 2-3 shift valve and low coast shift valve small end first. Install low coast shift valve plug with thin end first.
- Coat intermediate shift valve key with petroleum jelly prior to installation. Install 3-4 shift control valve cut side first. Install 3rd coast shift valve with flat end first.
- Install lower 1-2 shift valve flat end first. Install 1-2 shift plug thin end first.
