Removal & Installation (Full Floating)
Remove axle flange nuts. Using punch, remove lock washer cones. Use bolts in threaded flange holes to remove axle shaft. Remove oil seal with puller. To install, replace flange gasket and oil seal. Reverse removal procedure.
AXLE SPECIFICATIONS
| Application | In. (mm) |
|---|---|
| Shaft Runout | .059 (1.50) |
| Flange Runout | .004 (.10) |
