Motor - Seat Track - Front Passenger Seat - Remove and Replace: Notes

Last modified: 24/07/2023 17:17:07

Courtesy of TESLA, INC.

NOTE: See Personal Protection to make sure to wear proper PPE when performing below procedure.

Torque Specifications: Motor - Seat Track - Front Passenger Seat (Remove and Replace)

Description	Torque Value	Recommended Tools	Reuse/Replace	Notes
Front passenger seat fasteners (x4)	33.5 Nm (24.7 lbs-ft)	Torx Plus T45 socket Cordless Ratchet/Impact Driver Flex head ratchet/flex head torque wrench	Replace	Bolts are patched
Bolt that attaches the lift motor assembly to the rear RH link	18 Nm (13.3 lbs-ft)	Torx Bit T45 Stubby Ratchet/torque wrench 3 in extension Flex head ratchet/flex head torque wrench	Replace	Bolts are patched
Bolts (x2) that attach the RH side track assembly to the RH front seat cushion assembly	23 Nm (17.0 lbs-ft)	Torx T50 Bit Stubby 3 in extension Flex head ratchet/flex head torque wrench Cordless Ratchet/Impact Driver	Replace	Bolts are patched
