Aero Lens - Instrument Panel - Remove And Replace: Notes
Last modified: 17/10/2022 13:21:32
NOTE:
See Personal Protection
to make sure proper PPE is worn when performing the below procedure.
Revision History:
- 2023-04-20: Added note for additional ground strap PN for non-HW4 vehicles.
- 2023-03-31: Added note on reworked datums/mounting tabs.
WARNING:
This procedure is a DRAFT, although it has been validated. Warnings and Cautions might be missing. Follow safety requirements and use extreme caution when working on or near high voltage systems and components. Provide corrections and feedback to ServiceDevelopment@teslamotors.com.
NOTE:
Replacement aero lens assemblies may have had certain datums/mounting tabs removed. This is normal and does not negatively affect vehicle functionality.
