Foam - Bumper Beam - Front - Remove And Replace: Remove

  1. Remove the front fascia. See Fascia - Front (Remove and Install) .
  2. Remove the front bumper beam foam from the front bumper beam.
    NOTE: If the vehicle is equipped with pedestrian protection systems, disconnect and remove the pressure tube sensors from the front bumper beam foam.
    G14820222Courtesy of TESLA, INC.
