Home >> Tesla >> 2021 >> Model X Long Range Plus >> Repair and Diagnosis (Single Page) >> Accessories & Equipment >> Interior/Exterior Trim >> Interior Trim (Model X) (2 Of 2) >> Carpeting And Mats >> Gap Hider - Trunk (5 Seat) - Remove And Replace >> Remove

Gap Hider - Trunk (5 Seat) - Remove And Replace: Remove

  1. Open the LH and RH front doors.
  2. Lower the LH front window.
  3. Move the driver and front passenger seats fully forward.
  4. Open the LH and RH rear doors.
  5. Fold down the LH and RH 2nd row seats.
  6. Open the liftgate.
  7. Remove the rear trunk load floor. See TRUNK LOAD FLOOR - REAR (REMOVE AND REPLACE) .
  8. Remove the front trunk load floor. See TRUNK LOAD FLOOR - FRONT (REMOVE AND REPLACE) .
  9. Remove the trunk gap hider.
    G15398240Courtesy of TESLA, INC.
