Trim - A-Pillar - Lower - LH - Remove And Replace: Install

  1. Position the LH lower A-pillar trim onto the A-pillar, and then fasten the clips (x7) that attach the trim to the vehicle.
    G15084443Courtesy of TESLA, INC.
  2. Install the LH middle A-pillar trim. See Trim - A-Pillar - Middle - LH (Remove And Replace) .
