| F28 |
Window Lift Motor, Right Rear |
ALL |
| F29 |
Contactor Power |
ALL |
| F30 |
Window Lift Motor, Right Front |
ALL |
| F31 |
Forward Camera/Active Safety |
NCAP/DSS |
| F32 |
Door Controls, Right Side |
ALL |
| F33 |
12V Accessory Spare |
ALL |
| F34 |
Forward Camera Defog |
NCAP/DSS |
| F35 |
12V Accessory Outlet |
ALL |
| F36 |
Air Suspension Control, Valves |
ASC |
| F37 |
Window Lift Motor, Left Rear |
ALL |
| F38 |
Driver's Seat Memory |
ALL |
| F39 |
Window Lift Motor, Left Front |
ALL |
| F40 |
Rear Door Handles |
ALL |
| F41 |
Door Controls, Left Side |
ALL |
| F42 |
Power Liftgate |
PLG |
| F43 |
Perm. Power Sense, Brake Sw. |
ALL |
| F44 |
Charger, Charge Port |
ALL |
| F45 |
Passive Entry, Horns, Security |
ALL |
| F46 |
Body Controls, Group 2 |
ALL |
| F47 |
Glove Box Light, OBD-II |
ALL |
| F48 |
Body Controls, Group 1 |
ALL |
| F49 |
Instrument Cluster |
ALL |
| F50 |
Siren, Intrusion/Tilt Sensor |
SP01 |
| F51 |
Center Display |
ALL |
| F52 |
Rear Window Defrost Grid |
ALL |
| F53 |
Battery Management System |
ALL |
| F54 |
Wiper De-Icer |
ALL |
| F55 |
Left Front Seat Adjust Motor |
ALL |
| F56 |
Right Front Seat Adjust Motor |
ALL |
| F57 |
Cabin Fan |
ALL |
| F58 |
12V Outlet/Forward Camera Sub. |
ALL |
| F59 |
HVAC2 functions |
ALL |
| K3 |
12V Outlet Switch |
ALL |
| K4 |
Wiper De-Ice |
CW01 |
| K5 |
Rear Defrost Grid |
ALL |
| K6 |
HVAC2 functions |
ALL |
