When New Connecting Rod and Crankshaft are Used

Check pin journal grade [(0), (1), or (2)] on front of crankshaft, and select connecting rod bearing of the same grade.

Fig 1: Checking Pin Journal Grade On Crankshaft
G06441138Courtesy of SUZUKI OF AMERICA CORP.
NOTE: There is no grading for connecting rod big end diameter.
