Vacuum Hose Removal and Installation: Installation

  1. Mount the vacuum hose and ensure the connections are tight on each end.
  2. Check the function of the booster. Refer to the "POWER BOOSTER FUNCTIONAL CHECK :".
    Fig 1: Installing Vacuum Hose
    G04103288Courtesy of SUZUKI OF AMERICA CORP.
