Front Axle Shaft Bearing/Oil Seal: Removal

WARNING: This page is about a different car, the 2004 Suzuki XL-7, 2004 Suzuki Vitara, and 2004 Suzuki Grand Vitara. However, it is still accessible from the selected car via links, so may be relevant.

NOTE: For removing axle shaft bearing and oil of right side axle shaft assembly, drain differential gear oil. See Fig 1 .

Remove axle shaft assembly. See FRONT AXLE SHAFT .
Remove left axle shaft (1) by using tire lever (2) or the like. See Fig 2 .
Remove left side strut. See appropriate FRONT article in SUSPENSION.
Remove axle shaft oil seal (1), using plain screwdriver. See Fig 3 .
Remove circlip (2).
Remove axle shaft bearing (1) using the sliding shaft, bearing & oil seal remover. See Fig 4 .

Fig 1: Removing Axle Shaft Bearing & Oil Seal

Courtesy of SUZUKI OF AMERICA CORP.

Fig 2: Removing Left Axle Shaft

Courtesy of SUZUKI OF AMERICA CORP.

Fig 3: Removing Axle Shaft Oil Seal

Courtesy of SUZUKI OF AMERICA CORP.

Fig 4: Removing Axle Shaft Bearing

Courtesy of SUZUKI OF AMERICA CORP.
