Free Axle Hub

WARNING: This page is about a different car, the 2004 Suzuki Vitara. However, it is still accessible from the selected car via links, so may be relevant.

Check teeth of free axle hub (1) for wear, damage and any other faulty condition.

Fig 1: Checking Teeth Of Free Axle Hub For Wear

Courtesy of SUZUKI OF AMERICA CORP.
