Free Axle Hub

WARNING: This page is about a different car, the 2003 Suzuki XL-7 and 2003 Suzuki Grand Vitara. However, it is still accessible from the selected car via links, so may be relevant.

Check teeth of free axle hub (1) for wear, damage and any other faulty condition.

Fig 1: Checking Teeth Of Free Axle Hub
G01374701Courtesy of SUZUKI OF AMERICA CORP.
