Timing Chain Tensioner Adjuster No. 2

WARNING: This page is about a different car, the 2004 Suzuki Grand Vitara. However, it is still accessible from the selected car via links, so may be relevant.

Check shoe (1) for wear or damage.
Check that plunger slides smoothly.

Fig 1: Checking Timing Chain Tensioner Adjuster No. 2
Courtesy of SUZUKI OF AMERICA CORP.
