Free Axle Hub

WARNING: This page is about a different car, the 2004 Suzuki XL-7 and 2004 Suzuki Grand Vitara. However, it is still accessible from the selected car via links, so may be relevant.

Check teeth of free axle hub (1) for wear, damage, and any other abnormal condition.

Fig 1: Checking Teeth Of Free Axle Hub
G02281206Courtesy of SUZUKI OF AMERICA CORP.
