Diagnostic Aids

An intermittent condition is likely to be caused by poor connection to SDM terminal No. A11, poor connection at passenger-side air bag harness connector terminal No. B3 or B5, an open in CKT R/B or CKT B, a short from CKT R/B to B+ or malfunction in low pressure sensor circuit inside passenger-side air bag which would require replacement of passenger-side air bag.

Fig 1: DTC 38: Low Pressure Sensor Circuit Open Or Short To Ignition Or Low Pressure Detected

Courtesy of SUZUKI MOTOR CORP.
