DTC 37 - Low Pressure Sensor Shorted To Ground Or Ignition

WARNING: This page is about a different car, the 1996 Suzuki Esteem. However, it is still accessible from the selected car via links, so may be relevant.
WARNING: To avoid air bag deployment and injury when trouble shooting system, only use test 0quipment specified in diagnostic charts. Under no circumstances should battery powered test equipment or test light be used. carefully follow all instructions.
Fig 1: DTC 37 - Low Pressure Sensor Shorted To Ground Or Ignition
G96H05807Courtesy of SUZUKI MOTOR CORPORATION
