Rear Drive Shaft: Removal

WARNING: This page is about a different variant/trim than selected.
  1. Remove the extension case. Ref. to CONTINUOUSLY VARIABLE TRANSMISSION (TR690)>EXTENSION CASE>REMOVAL
  2. Remove the rear drive shaft.
    G14611261Courtesy of SUBARU OF AMERICA, INC.
