Center Antenna

CAUTION:
  • Before handling the airbag system components, refer to "CAUTION" of "General Description" in "AIRBAG SYSTEM". Ref. to  AIRBAG SYSTEM>GENERAL DESCRIPTION>CAUTION
  • The center antenna assembly is installed near the Side impact sensor (under the rear center seat) of the airbag system. Be careful not to apply strong impact to the Side impact sensor (under the rear center seat) when working with the center antenna assembly removed.
NOTE:

Do not detach the antenna except when replacing it. Detaching unnecessarily will lead to insecure attachment of the antenna.

  1. Disconnect the ground terminal from the battery sensor, and wait for at least 60 seconds before starting work. Ref. to REPAIR CONTENTS>NOTE>BATTERY
  2. Remove the rear seat cushion assembly. Ref. to SEATS>REAR SEAT>REMOVAL
  3. Remove the center antenna assembly interior.
    1. Disconnect the connector.
    2. Remove the screw, and remove the center antenna assembly interior.
      G14612841Courtesy of SUBARU OF AMERICA, INC.
