| MB-1 |
Rear defogger relay |
| MB-2 |
Outer mirror ASSY LH |
| Outer mirror ASSY RH |
| MB-3 |
Combination switch |
| Front wiper motor |
| Wiper relay unit |
| MB-4 |
Washer motor |
| MB-7 |
Blower motor relay |
| MB-8 |
Front power window motor LH |
| Power window main switch |
| MB-10 |
VSC (VDC) Control Module |
| MB-11 |
VSC (VDC) Control Module |
| MB-12 |
Main fan motor ASSY |
| MB-13 |
Sub fan motor ASSY |
| MB-14 |
A/C relay |
| MB-16 |
Front power window motor RH |
| MB-19 |
Starter cut relay |
| MB-20 |
ID code box |
| Keyless access Control Module |
| MB-21 |
Clutch start switch |
| MB-22 |
Driver's door unlock relay |
| Lock relay |
| Passenger's door unlock relay |
| Trunk unlock relay |
| MB-23 |
Data communication module |
| MB-24 |
A/C control panel |
| Body integrated unit |
| Central gateway Control Module |
| Combination meter |
| RAB Control Module |
| MB-25 |
Cockpit control module |
| MB-26 |
Front door step light LH |
| Front door step light RH |
| Spot map light |
| Trunk room light |
| Vanity mirror light LH |
| Vanity mirror light RH |
| Warning box |
| MB-27 |
Active sound control Control Module |
| Body integrated unit |
| MB-28 |
Steering lock Control Module |
| MB-29 |
Body integrated unit |
| MB-30 |
Body integrated unit |
| MB-31 |
Power steering Control Module |
| MB-32 |
Battery sensor |
| MB-33 |
ECM |
| MB-34 |
TCM |
| MB-38 |
Fuel pump relay |
| MB-39 |
ECM |
| Fuel pump relay |
| Starter cut relay |
| Starter relay |
| MB-40 |
Airbag Control Module |
| MB-41 |
Exhaust camshaft position sensor LH |
| Exhaust camshaft position sensor RH |
| Fuel injector (for direct injection) No. 1 |
| Fuel injector (for direct injection) No. 2 |
| Fuel injector (for direct injection) No. 3 |
| Fuel injector (for direct injection) No. 4 |
| Intake camshaft position sensor LH |
| Intake camshaft position sensor RH |
| Leak check valve ASSY |
| Purge control solenoid valve |
| MB-42 |
Exhaust oil control solenoid LH |
| Exhaust oil control solenoid RH |
| Intake oil control solenoid LH |
| Intake oil control solenoid RH |
| MB-43 |
Front oxygen (A/F) sensor |
| Rear oxygen sensor |
| MB-44 |
Ignition coil No. 1 |
| Ignition coil No. 2 |
| Ignition coil No. 3 |
| Ignition coil No. 4 |
| MB-45 |
ECM |
| MB-51 |
ECM |
| MB-52 |
Battery sensor |
| MB-53 |
Airbag Control Module |
| MB-54 |
Front combination light RH |
| MB-55 |
Front combination light LH |
| MB-56 |
Body integrated unit |
| MB-57 |
Body integrated unit |
| MB-58 |
Front combination light RH |
| MB-59 |
Front combination light LH |
| MB-60 |
Body integrated unit |
| MB-61 |
Body integrated unit |
| MB-62 |
Horn LH |
| MB-63 |
Horn RH |
| MB-64 |
Body integrated unit |
| Roll connector |
| MB-65 |
Intake door actuator |
| FB-2 |
Keyless access Control Module |
| FB-7 |
EyeSight security gateway Control Module |
| Stereo camera |
| FB-8 |
Auto headlight beam leveler Control Module |
| Cockpit control module |
| FB-12 |
Audio amplifier |
| FB-16 |
Front combination light RH |
| Side marker light RH |
| FB-17 |
Front combination light LH |
| Side marker light LH |
| FB-19 |
License plate light LH |
| License plate light RH |
| Rear combination light LH |
| Rear combination light RH |
| FB-21 |
A/C control panel |
| Cockpit control module |
| Console switch |
| Front seat heater switch |
| Hazard switch |
| Illumination control switch |
| Passenger's door lock switch |
| Roll connector |
| Shift position indicator |
| TPMS set switch |
| Trunk lid opener switch |
| FB-22 |
Telematics button |
| FB-23 |
Power window main switch |
| FB-25 |
Body integrated unit |
| FB-26 |
Power window main switch |
| FB-28 |
Data communication module |
| FB-29 |
Central gateway Control Module |
| FB-31 |
Front accessory power supply socket |
| FB-34 |
A/C control panel |
| FB-35 |
Sub fan motor ASSY |
| FB-36 |
Daytime running light LH relay |
| Daytime running light RH relay |
| FB-37 |
VSC (VDC) Control Module |
| FB-38 |
Auto headlight beam leveler Control Module |
| Data link connector |
| Front combination light LH |
| Front combination light RH |
| FB-39 |
Power steering Control Module |
| FB-41 |
Steering angle sensor |
| FB-43 |
Radar sensor LH (master) |
| Radar sensor RH (slave) |
| TPMS Control Module |
| FB-44 |
Power window main switch |
| FB-45 |
Back-up light switch |
| Inhibitor switch |
| FB-47 |
EyeSight security gateway Control Module |
| OP connector (rearview mirror) |
| RAB Control Module |
| Stereo camera |
| Warning box |
| FB-48 |
Daytime running light RH relay |
| FB-49 |
Active sound control Control Module |
| Cockpit control module |
| FB-50 |
Front seat heater switch |
| FB-52 |
A/C control panel |
| FB-53 |
Blower motor relay |
| FB-55 |
Main fan motor ASSY |
| FB-57 |
Rear defogger relay |
| FB-58 |
Pressure switch |
| FB-59 |
Data link connector |
| FB-62 |
Stop light & brake switch |
| Stop light relay |
| FB-67 |
Clutch switch |
| ECM |
| Stop light & brake switch |
| Stop light relay |
| FB-69 |
Central gateway Control Module |
| FB-70 |
Data communication module |
| FB-71 |
Combination meter |
| FB-73 |
Steering lock Control Module |
| FB-76 |
TCM |
