| MB-1 |
Blower motor relay |
| MB-2 |
Power amplifier |
| MB-3 |
Audio |
| DC/DC converter 1 |
| Navigation unit |
| MB-4 |
DC/DC converter 1 |
| MB-5 |
VDC Control Module |
| MB-6 |
VDC Control Module |
| MB-7 |
Wiper deicer relay |
| MB-8 |
DC/DC converter 2 |
| MB-9 |
Rear defogger relay |
| MB-10 |
Front fog light relay |
| MB-11 |
Main fan relay 1 |
| MB-12 |
Sub fan relay |
| MB-13 |
Front wiper motor |
| Combination switch |
| MB-14 |
Front washer motor |
| MB-15 |
Rear washer motor |
| Rear wiper motor |
| Rear wiper relay |
| MB-16 |
Power steering Control Module |
| MB-17 |
Data link connector |
| MB-18 |
ECM |
| Battery sensor |
| TCM |
| MB-19 |
Battery sensor |
| Electric fluid pump relay |
| MB-20 |
Horn LH |
| MB-21 |
Horn RH |
| MB-22 |
Body integrated unit |
| Horn switch |
| MB-23 |
Starter cut relay |
| MB-24 |
EGR control valve |
| Intake camshaft position sensor LH |
| Intake camshaft position sensor RH |
| Leak check valve ASSY |
| Purge control solenoid valve |
| Exhaust camshaft position sensor RH |
| Exhaust camshaft position sensor LH |
| MB-26 |
Intake oil control solenoid LH |
| Intake oil control solenoid RH |
| Exhaust oil control solenoid RH |
| Exhaust oil control solenoid LH |
| MB-27 |
Front oxygen (A/F) sensor |
| Rear oxygen sensor |
| MB-28 |
Ignition coil No. 1 |
| Ignition coil No. 2 |
| Ignition coil No. 3 |
| Ignition coil No. 4 |
| MB-29 |
ECM |
| MB-31 |
TCM |
| MB-32 |
Primary speed sensor |
| Secondary speed sensor |
| Turbine speed sensor |
| MB-33 |
ECM |
| MB-34 |
Fuel pump relay |
| MB-35 |
Front combination light RH |
| MB-36 |
Front combination light LH |
| MB-37 |
Body integrated unit |
| Daytime running light relay |
| MB-38 |
Body integrated unit |
| MB-39 |
Power window circuit breaker |
| MB-41 |
Data communication module |
| MB-50 |
Front lock relay |
| Front unlock relay |
| Rear gate unlock relay |
| Body integrated unit |
| MB-51 |
Occupant detection Control Module |
| MB-52 |
Body integrated unit |
| MB-53 |
Body integrated unit |
| MB-54 |
Body integrated unit |
| MB-55 |
Body integrated unit |
| BU-1 |
Body integrated unit |
| BU-2 |
Body integrated unit |
| Front lock relay |
| Front unlock relay |
| Rear gate unlock relay |
| FB-1 |
Stop light & brake switch |
| Stop light relay |
| FB-3 |
Steering heater relay |
| FB-4 |
Body integrated unit |
| FB-5 |
Trailer connector |
| FB-6 |
A/C control panel |
| Body integrated unit |
| FB-7 |
Keyless access Control Module |
| FB-8 |
Body integrated unit |
| FB-10 |
Combination meter |
| FB-11 |
A/C control panel |
| FB-12 |
TPMS Control Module |
| FB-14 |
Auto headlight beam leveler Control Module |
| FB-15 |
A/C control panel |
| FB-16 |
Audio |
| Navigation unit |
| FB-18 |
MFD |
| FB-19 |
Outer mirror ASSY RH |
| Remote engine start Control Module connector |
| FB-20 |
Immobilizer antenna (without push button start) |
| FB-21 |
Outer mirror ASSY LH |
| FB-22 |
Luggage room light |
| FB-23 |
Warning box |
| Vanity mirror light RH |
| Room light |
| Vanity mirror light LH |
| Spot map light |
| FB-24 |
Body integrated unit |
| FB-25 |
Combination meter |
| MFD |
| FB-26 |
Radar sensor LH (master) |
| Radar sensor RH (slave) |
| Shift position indicator |
| FB-27 |
Stereo camera |
| Warning box |
| FB-28 |
A/C control panel |
| FB-30 |
ID code box |
| Steering lock Control Module |
| Keyless access Control Module |
| FB-31 |
Body integrated unit |
| FB-32 |
MFD |
| FB-36 |
Clutch start switch |
| keyless access Control Module |
| FB-37 |
Stereo camera |
| RAB Control Module |
| FB-38 |
Remote control mirror switch |
| Rear view mirror |
| FB-39 |
Seat heater switch |
| Front accessory power supply socket |
| FB-40 |
Rear accessory power supply socket (console) |
| FB-41 |
Daytime running light relay |
| FB-42 |
Steering lock Control Module |
| FB-43 |
Blower motor relay |
| FB-44 |
Data communication module |
| A/C control panel |
| Intake door actuator |
| FB-45 |
Pressure switch |
| Rear defogger relay |
| Sub fan relay |
| Wiper deicer relay |
| FB-46 |
TPMS Control Module |
| TPMS & keyless entry Control Module |
| Radar sensor LH (master) |
| RAB Control Module |
| Radar sensor RH (slave) |
| Keyless entry Control Module (without push button start) |
| FB-47 |
BSD/RCTA OFF switch |
| Data link connector |
| Remote engine start Control Module connector |
| FB-48 |
Warning box |
| Sunroof unit |
| FB-49 |
Clutch switch |
| Stop light & brake switch |
| FB-50 |
Power window relay |
| FB-51 |
ECM |
| Main fan relay 1 |
| Main fan relay 2 |
| FB-53 |
Front combination light LH |
| Front combination light RH |
| Auto headlight beam leveler Control Module |
| Back-up light switch |
| Inhibitor switch |
| FB-54 |
AUX input terminal (console) |
| AUX input terminal (instrument panel) |
| Data communication module |
| Audio |
| Audio amplifier |
| FB-55 |
A/C control panel |
| FB-56 |
Steering heater relay |
| Body integrated unit |
| FB-57 |
DC/DC converter 1 |
| FB-58 |
VDC Control Module |
| Stop light relay |
| FB-59 |
Steering angle sensor |
| FB-60 |
Power steering Control Module |
| FB-61 |
MFD |
| FB-62 |
Combination meter |
| FB-63 |
Airbag Control Module |
| FB-64 |
Occupant detection Control Module |
| FB-66 |
DC/DC converter 1 |
| DC/DC converter 2 |
| FB-67 |
ECM |
| Fuel pump relay |
| Starter cut relay |
| Starter relay |
| TCM |
