Section 1 (Automatic Transaxle (Service Information))
>>
Automatic Transmission ASSY
>>
Exploded View
Exploded View
WARNING:
This page is about a different variant/trim than selected.
Fig 1: Automatic Transmission Assembly Components With Torque Specification (1 Of 2)
Courtesy of SUBARU OF AMERICA, INC.
Fig 2: Automatic Transmission Assembly Components With Torque Specification (2 Of 2)
Courtesy of SUBARU OF AMERICA, INC.
