DTC B16F1 Passenger's Seat Belt Warning Failure: Wiring diagram

Seat belt warning system Ref. to WIRING SYSTEM>Seat Belt Warning System .

Fig 1: Passenger Seat Belt Warning Failure System Wiring Diagram

Courtesy of SUBARU OF AMERICA, INC.

CAUTION: Before performing diagnosis, refer to "CAUTION" in "General Description". Ref. to AIRBAG (DIAGNOSTICS)>General Description>CAUTION .

Fig 2: Passenger Seat Belt Warning Failure Diagnostics Flowchart

Courtesy of SUBARU OF AMERICA, INC.
