DTC B1647 Side Satellite Sensor Bus LH Lost Communication: DTC detecting condition
- Open circuit in harness between airbag control module and side airbag sensor LH, and between side airbag sensor LH and curtain airbag sensor LH.
- Satellite sensor bus LH circuit shorted, shorted to ground or shorted to power supply.
CAUTION:
Before performing diagnosis, refer to "CAUTION" in "General Description". Ref. to AIRBAG (DIAGNOSTICS)>General Description>CAUTION .
