Clutch Pipe and Hose: Installation

WARNING: This page is about a different variant/trim than selected.

Install in the reverse order of removal.

NOTE: Bleed air from brake fluid. Ref. to CLUTCH SYSTEM>Clutch Fluid Air Bleeding .

Tightening torque:

T1: 15 N.m (1.5 kgf-m, 11.1 ft-lb)

T2: 18 N.m (1.8 kgf-m, 13.3 ft-lb)

T3: 25 N.m (2.5 kgf-m, 18.4 ft-lb)

Fig 1: Exploded View Of Clutch Pipe And Hose Components

Courtesy of SUBARU OF AMERICA, INC.

Tightening torque:

Air intake boot

3 N.m (0.3 kgf-m, 2.2 ft-lb)
