| MB-1 |
VDC control module |
| MB-2 |
VDC Control Module |
| MB-4 |
Sub fan relay |
| MB-5 |
Mirror heater LH |
| Mirror heater RH |
| Rear defogger |
| A/C control panel (manual A/C) |
| MB-6 |
Body integrated unit |
| MB-7 |
Main fan relay 2 |
| MB-8 |
Main fan motor |
| MB-9 |
ECM |
| MB-10 |
Main fan relay 2 |
| MB-11 |
Main fan relay 2 |
| MB-12 |
Body integrated unit |
| MB-13 |
Body integrated unit |
| Daytime running light relay LH (halogen model) |
| Daytime running light relay RH (halogen model) |
| MB-16 |
Front combination light LH |
| Front combination light RH |
| MB-17 |
Daytime running light relay LH (halogen model) |
| Daytime running light relay RH (halogen model) |
| Front combination light LH |
| Front combination light RH |
| MB-18 |
Body integrated unit |
| MB-19 |
Horn |
| MB-20 |
Horn |
| MB-21 |
Horn switch |
| Body integrated unit |
| MB-22 |
A/F, oxygen sensor relay |
| MB-23 |
Main relay |
| IG relay |
| MB-24 |
Electronic throttle control relay |
| MB-25 |
Fuel pump relay |
| MB-26 |
TCM |
| Self shut relay |
| MB-27 |
ECM |
| Data link connector |
| Battery sensor |
| MB-28 |
Turn signal and hazard unit |
| Body integrated unit |
| Key warning switch |
| MB-29 |
Body integrated unit |
| Navigation unit |
| Audio |
| MB-30 |
Power window circuit breaker |
| MB-32 |
Tail & Illumination relay |
| Daytime running light relay (LED model) |
| Daytime running light relay LH (halogen model) |
| Daytime running light relay RH (halogen model) |
| MB-33 |
Wiper relay |
| MB-34 |
Brake pump relay |
| Data communication module |
| Steering heater relay |
| ALT-1 |
OP connector |
| ALT-2 |
ECM |
| Battery sensor |
| ST-1 |
Clutch start switch |
| Starter relay 1 |
| ST-2 |
Starter relay 1 |
| FB-1 |
Trailer connector |
| FB-3 |
Stop light and brake switch |
| Stop light relay |
| FB-4 |
Wiper deicer relay |
| FB-5 |
Seat heater relay |
| FB-6 |
Body integrated unit |
| Remote control back rest switch LH |
| Remote control back rest switch RH |
| FB-8 |
Blower motor relay |
| FB-9 |
Front fog light relay (without SRF) |
| Front fog light relay LH (with SRF) |
| Front fog light relay RH (with SRF) |
| FB-10 |
Rear seat heater Control Module |
| FB-11 |
Overhead console (spot map light) |
| Body integrated unit |
| Immobilizer antenna |
| Door step light LH |
| Door step light RH |
| Outer mirror assembly LH |
| Outer mirror assembly RH |
| Room light |
| Stereo camera cover (spot map light) |
| Luggage room light |
| Keyless entry Control Module |
| TPMS & keyless entry Control Module |
| MFD |
| Memory height switch |
| VDC OFF & power rear gate driver's switch |
| Puddle light LH |
| Puddle light RH |
| Vanity mirror LH |
| Vanity mirror RH |
| Power rear gate inner switch |
| FB-17 |
Combination meter |
| Body integrated unit |
| A/C control panel (auto A/C) |
| Power rear gate Control Module |
| RAB Control Module |
| FB-18 |
Security Control Module |
| Steering lock Control Module |
| Impact sensor |
| Air mix door actuator LH (with left/right independent air conditioner) |
| Air mix door actuator RH (with left/right independent air conditioner) |
| Mode door actuator (auto A/C) |
| Air mix door actuator (without left/right independent air conditioner) |
| Stereo camera |
| FB-20 |
Seat heater relay |
| Rear view mirror |
| Remote control mirror switch |
| FB-21 |
Rear accessory power supply socket |
| FB-22 |
Front accessory power supply socket |
| FB-25 |
Audio |
| Navigation unit |
| Data communication module |
| FB-28 |
A/C control panel |
| FB-29 |
Body integrated unit |
| FB-30 |
BSD/RCTA OFF switch |
| Radar sensor LH (master) |
| Radar sensor RH (slave) |
| TPMS & keyless entry Control Module |
| Rear seat heater Control Module |
| FB-31 |
Power rear gate Control Module |
| RAB Control Module |
| Power seat LH (with seat position memory) |
| FB-32 |
Sunroof switch |
| Clutch switch |
| Sunroof unit |
| Data link connector |
| Stop light and brake switch |
| Wiper deicer relay |
| Impact sensor |
| Stereo camera |
| Steering heater relay |
| Steering heater switch |
| FB-34 |
Turn signal and hazard unit |
| FB-35 |
Inhibitor switch |
| Headlight washer unit |
| Auto headlight beam leveler Control Module |
| Daytime running light relay (LED model) |
| Front combination light LH (SRH actuator) |
| Front combination light RH (SRH actuator) |
| FB-36 |
Combination meter |
| MFD |
| FB-37 |
Data communication module |
| FB-38 |
ECM |
| TCM |
| Body integrated unit |
| Fuel pump relay |
| Combination switch |
| FB-41 |
Airbag Control Module |
| FB-42 |
Power window relay |
| Wiper relay |
| FB-43 |
Steering lock Control Module |
| FB-44 |
VDC Control Module |
| Steering angle sensor |
| Power steering Control Module |
| Stop light relay |
| Yaw rate & G sensor |
| FB-45 |
A/C control panel |
| FB-46 |
A/C relay |
| Sub fan relay |
| Pressure switch |
| Blower motor relay |
| FB-47 |
Occupant detection control module |
| BAT-1 |
Power steering Control Module |
