Front Antenna

  1. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work. Ref. to NOTE>NOTE>BATTERY .
    NOTE: For model with battery sensor, disconnect the ground terminal from battery sensor.
  2. Remove the tray assembly - CTR. Ref. to EXTERIOR/INTERIOR TRIM>Console Box>REMOVAL .
  3. Disconnect the connector and remove the front antenna assembly - interior.
Fig 1: Removing Front Antenna Assembly - Interior
G09484721Courtesy of SUBARU OF AMERICA, INC.
