Wiper Blade: Removal: Front

  1. Lift up the locking clip (A).
  2. Turn the blade assembly - windshield wiper in the arrow direction.
  3. Push in the arm assembly - windshield wiper.
  4. Pull out the arm assembly - windshield wiper while pulling it up, and remove the blade assembly - windshield wiper from the arm assembly - windshield wiper.
Fig 1: Lifting Up Locking Clip
G06653522Courtesy of SUBARU OF AMERICA, INC.
