Hazard Switch: Removal

  1. Disconnect the ground cable from battery. Ref. to NOTE>NOTE>BATTERY .
    NOTE: For model with battery sensor, disconnect the ground terminal from battery sensor.
  2. Remove the center grille assembly. Ref. to HVAC SYSTEM (HEATER, VENTILATOR AND A/C)>Air Vent Grille>REMOVAL>CENTER GRILLE ASSEMBLY .
  3. Release the claws, and then remove the switch - hazard.
Fig 1: Locating Switch - Hazard Claws
G10408191Courtesy of SUBARU OF AMERICA, INC.
