Door Step Light: Removal

  1. Disconnect the ground cable from battery. Ref. to NOTE>NOTE>BATTERY .
    NOTE: For model with battery sensor, disconnect the ground terminal from battery sensor.
  2. Remove the door step light.
    1. Insert a flat tip screwdriver into the slit of the door step light to release the claw.
      CAUTION: When using a flat tip screwdriver, use an appropriate sized tool for the insertion opening, apply protective tape or cloth around the tool, and be careful not to cause damage.
    2. Disconnect the connector and remove the door step light and bulb.
      CAUTION: Use a dry clean cloth so that no grease or water adheres to the glass portion of the bulb.
Fig 1: Disconnecting Door Step Light Connector
G11268548Courtesy of SUBARU OF AMERICA, INC.
