BSD/RCTA Off Switch

  1. Disconnect the ground cable from battery. Ref. to NOTE>NOTE>BATTERY .
    NOTE: For model with battery sensor, disconnect the ground terminal from battery sensor.
  2. Remove the cover assembly - instrument panel LWR driver. Ref. to EXTERIOR/INTERIOR TRIM>Instrument Panel Lower Cover>REMOVAL .
  3. Release the claws and remove the BSD/RCTA OFF switch.
Fig 1: Identifying BSD/RCTA OFF Switch And Claws
G11272175Courtesy of SUBARU OF AMERICA, INC.
