Center Console Duct

  1. Remove the console box. Refer to REMOVAL .
  2. Remove the screws, and remove the center console duct.
    Fig 1: Locating Center Console Duct Screws
    G08583926Courtesy of SUBARU OF AMERICA, INC.
