R Range
WARNING: This page is about a different variant/trim than selected.
- Front brake operates to fix the front sun gear.
- High&low reverse clutch engages and connects mid sun gear and rear sun gear.
- Reverse brake operates to fix the rear carrier.
Courtesy of SUBARU OF AMERICA, INC.
