10.5th GEAR IN D RANGE OR MANUAL MODE
WARNING: This page is about a different variant/trim than selected.
- Front brake operates to fix the front sun gear.
- Input clutch engages and connects front internal gear and mid internal gear.
- High&low reverse clutch engages and connects mid sun gear and rear sun gear.
Courtesy of SUBARU OF AMERICA, INC.
