P0306

DTC P0306 CYLINDER 6 MISFIRE DETECTED

DTC DETECTING CONDITION:
- Detected when two consecutive driving cycles with fault occur.
- Immediately at fault recognition (A misfire which could damage catalyst occurs.)
- GENERAL DESCRIPTION P0306

TROUBLE SYMPTOM:
- Engine stalls.
- Improper idling
- Rough driving

CAUTION: After servicing or replacing faulty parts, perform Clear Memory Mode, and Inspection Mode. Clear Memory Mode Inspection Mode

WIRING DIAGRAM:
