P1817

DTC P1817 SPORTS MODE SWITCH CIRCUIT (MANUAL SWITCH)

DTC DETECTING CONDITION:
Input signal circuit of sport/manual mode switch is shorted.

TROUBLE SYMPTOM:
- Manual mode can not be set.
- The AT OIL TEMP light does not illuminate.
- No sport mode occurs.

WIRING DIAGRAM:
