P0801

DTC P0801 REVERSE INHIBIT CONTROL CIRCUIT

DTC DETECTING CONDITION:
Shift lock solenoid malfunction, open or short reverse inhibitor control circuit

TROUBLE SYMPTOM:
- Gear is shifted from "N" range to "R" range during driving at 20 km/h (12 MPH) or more.
- Gear cannot be shifted from "N" range to "R" range.

WIRING DIAGRAM:
