P0763

DTC P0763 SHIFT SOLENOID "C" ELECTRICAL

DTC DETECTING CONDITION:
Output signal circuit of high clutch duty solenoid is open or shorted.

TROUBLE SYMPTOM:
Excessive shift shock

WIRING DIAGRAM:
