P0724
DTC P0724 BRAKE SWITCH CIRCUIT HIGHDTC DETECTING CONDITION:
Brake switch malfunction, open input signal circuit
TROUBLE SYMPTOM:
- Gear is not shifted down when driving a down hill.
- Neutral control does not operate.
WIRING DIAGRAM:
DTC DETECTING CONDITION:
Brake switch malfunction, open input signal circuit
TROUBLE SYMPTOM:
- Gear is not shifted down when driving a down hill.
- Neutral control does not operate.
WIRING DIAGRAM:
