P0720

DTC P0720 OUTPUT SPEED SENSOR CIRCUIT

DTC DETECTING CONDITION:
- The vehicle speed signal is abnormal.
- The harness connector between TCM and vehicle speed sensor is shorted or open.

TROUBLE SYMPTOM:
- Neutral control does not operate.
- Slip lock-up control does not operate.
- Driving performance is poor.

WIRING DIAGRAM:
