Cruise Control

DTC 11

Detected when main switch is pressed or when main switch related malfunction occurs.

TROUBLE SYMPTOM:
- Cruise control cannot be set. (Cancelled immediately.)
- Cruise control cannot be released.

WIRING DIAGRAM:
