B1104

DTC B1104 ACC POWER FAILURE

DTC DETECTING CONDITION:
- Open or short in ACC power supply circuit
- Voltage malfunction caused by poor contact

TROUBLE SYMPTOM:
Does not exist.

NOTE: B1104 may output when the ignition switch turns to ACC with the weak battery condition.

WIRING DIAGRAM:
