B1103
DTC B1103 IGNITION POWER FAILUREDTC DETECTING CONDITION:
- Open or short in IGN power supply circuit
- Voltage malfunction caused by poor contact
TROUBLE SYMPTOM:
Error related to LAN system will not be detected.
NOTE: B1103 may output when the ignition switch turns to ON with the weak battery condition.
WIRING DIAGRAM:
