B1101

DTC B1101 BATT P/SUPPLY MALFUNCTION CONT

DTC DETECTING CONDITION:
- Open or short in battery power supply control circuit
- Voltage malfunction caused by poor contact

TROUBLE SYMPTOM:
Each function stops operation.

NOTE:
- When B1102 BATT p/supply (backup) malfunction is output at the same time, all the function of body integrated unit may not operate.
- B1101 may input when the battery run-out occurs.

WIRING DIAGRAM:
